51021-0200 (1.25mm Pitch PicoBlade™)
51021-0200 (1.25mm Pitch PicoBlade™)
51021-0200 (1.25mm Pitch PicoBlade™)
51021-0200 (1.25mm Pitch PicoBlade™)
51021-0200 (1.25mm Pitch PicoBlade™)
51021-0200 (1.25mm Pitch PicoBlade™)

51021-0200 (1.25mm Pitch PicoBlade™)

일반적 특성

가격0원
제조사molex
MOQ1,000PC
TMLmolex
제품문의
제품 상세정보

일반적 특성

현황Active
Category크림프 하우징
시리즈51021
적용제품Signal, 와이어 대 보드, 와이어 대 와이어
전체보기PicoBlade™ Connector System
제품명PicoBlade™
UPC800753575592

물리적 특성

최대 회로수2
색상 - 플라스틱천연색
난연성94V-0
암수구분암
Glow-Wire 적용No
결합제품 잠금장치Yes
원재료 - 플라스틱Polyester
Net Weight26.150/mg
열 수1
포장타입백 (Bag)
패널마운트No
피치 - 결합부1.25mm
결합제품 오삽입 장치Yes
End-to-End 연결형No
사용온도 범위-40°C to +85°C

전기적 특성

(Please review the Product Specification for specific details.)
전류 - 접촉 당 최대 출력0.8A, 1A

Agency Certification

Please find UL Certificates by searching the UL Database using the Molex Series Number. Click here to visit the UL Database

CSALR19980
ULE29179

원재료 정보

납땜 프로세스 정보

참고 - 도면번호

Packaging
Specification		SPK-51021-001
제품규격PS-51021-001, PS-51021-002, PS-51021-009, PS-51021-010, PS-51021-011, PS-51021-022, PS-51021-023, PS-51021-024, PS-51021-025, PS-51021-026, PS-51021-027, PS-51021-028, RPS-51021-001, RPS-51021-002, RPS-51021-003, RPS-51021-004, RPS-51021-006, RPS-51021-007, RPS-51021-008, RPS-51021-009, RPS-51021-010, RPS-51021-011, RPS-51021-012, RPS-51021-013, RPS-51021-014, RPS-51021-015, RPS-51021-018, RPS-51021-020, RPS-51021-021, RPS-51021-023, RPS-51021-024, RPS-51021-025, RPS-51021-028, RPS-51021-030, RPS-51021-031, RPS-51021-032, RPS-51021-033, RPS-51021-034, RPS-51021-037, RPS-51021-038, RPS-51021-039, RPS-51021-040, RPS-51021-041, RPS-51021-042, RPS-51021-043, RPS-51021-044, RPS-51021-045, RPS-51021-046, RPS-51021-047, RPS-51021-048, RPS-51021-051, RPS-51021-052, RPS-51021-053, RPS-51021-054, RPS-51021-055, RPS-51021-056, RPS-51021-057, RPS-51021-058, RPS-51021-059, RPS-51021-060, RPS-51021-061, RPS-51021-062, RPS-51021-063, RPS-51021-064, RPS-51021-065, RPS-51021-066, RPS-51021-067, RPS-51021-068, RPS-51021-071, RPS-51021-072, RPS-51021-073, RPS-51021-074, RPS-51021-076, RPS-51021-077, RPS-51021-079, RPS-51021-080, RPS-51021-081, RPS-51021-084, RPS-51021-085, RPS-51021-086, RPS-51021-089, RPS-51021-091, RPS-51021-092, RPS-51021-096, RPS-51021-097, RPS-51021-101, RPS-51021-102, RPS-51021-103, RPS-51021-104, RPS-51021-105, RPS-51021-107, RPS-51021-108, RPS-51021-112, RPS-51021-114, RPS-51021-117, RPS-51021-118, RPS-51021-121, RPS-51021-122, RPS-53398-002, RPS-53398-037, RPS-53398-038, RPS-53398-039
도면SD-51021-002, SD-51021-005
